Metal Taylor wreath

Hits:2259  Time:2020-01-16


Metal Taylor garland packing is made of metal sheet stamping and stretching into a special rolling mesh, with regular diamond mesh holes on the surface to maintain the geometric rules of wire mesh corrugated packing. The packing of the garland is divided into plastic packing and metal packing. Plastic garland packing appeared earlier, and more used in gas washing, purification tower.



Low filling the void fraction of big, not easy to be blocked, and the advantages of large flux, small resistance, the wreath packing also called plum flower ring packing is composed of many circle knot around, because of the packing space have higher amount of the liquid, due to the packing of gaps have higher delay fluid volume, can make the liquid in the tower to stay for a long time, thus increasing the contact time of gas and liquid, improve the efficiency of the packing mass transfer. Polypropylene packing has the characteristics of large void, low pressure drop and mass transfer unit height, high flooding point, adequate vapor-liquid contact, small specific gravity, high mass transfer efficiency, which is mostly used in gas washing and purification tower.

● reinforced polypropylene garland has longer service life, better chemical corrosion resistance, and improved mechanical properties, creep resistance and dimensional stability than polypropylene garland packing. Our company adopts the reinforced polypropylene glass fiber produced by Beijing institute of chemical engineering, and the product has a temperature resistance of 127℃ and a thermal deformation temperature of 160℃. With high strength, chemical corrosion resistance, good electrical insulation, impact resistance and many other aspects of the excellent performance, and good toughness resistance.

● metal ring packing because of the filler gap can have a higher liquid holding capacity, can make the liquid in the tower stay longer, thus increasing the gas-liquid contact time, improve the mass transfer efficiency of the packing.



sizenumberarea

Void

fraction

50*25*0.819180112.896.2
75*75*1.0546064.197.3
100*45*1.2252053.497.3
